One of the most talked about DIY high end power cables in the world.. Available in your country now. Contact your local Furutech distributor for more information.
Conductor: α (Alpha)-OCC Conductor (49 / 0.32mm (2.5mm)) (≒11 AWG) / (3.94 sq.mm)
Insulation: PE (Red, Natural, Yellow)
Red=Live Yellow=Neutral Clear=Earth
Twisting: 3 Cores Twisted Together
Sheath: Flexible PVC (Green)
Max. Conductor Resistance: 0.0052Ω/ M
Overall Diameter: 15mm
Item Specification Test Method
Max. Conductor Resistance Ω/km 5.2 JISC3005 6 20℃
Min. Insulation Resistance MΩ‧km 2500 JISC3005 9.1 20℃
Dielectric Strength V/1 min AC 3000 JISC3005 8
