2 Type stranding
14AWG α (Alpha) conductor(2.16 Sq.mm)
※α (Alpha)-OCC Conductor：The PCOCC wire strands and treated with the α(Alpha) process
・Conductor: α (Alpha)-OCC Conductor(56/0.18mm（central）+ 29/0.18mm（outside） (14 AWG) / (2.16 sq.mm)
・Insulation: PE(Red、Natural、Yellow) Red=Live、Yellow=Neutral、Clear=Earth.
・Twisting: 3 Cores Twisted Together
・Shield: 0.12mm α (Alpha) Conductor wire Braid
・Sheath: Flexible PVC (Dark Blue)
・Max. Conductor Resistance: 0.008Ω/ M
・Overall Diameter: 14.3mm (14 AWG)
